W10314173 661570 W10837240 Dryer Repair Set For Whirlpool / Kenmore

Replacement drum rollers, idler, and belt used for some Amana, Kenmore, KitchenAid, Maytag and Whirlpool dryer models.

Directly Replaces: WPW10314173, W10314173, WPW10314173VP, W10314171, W10756057, 3388342, 3389902, 3396801, 3396802, 3401846, 8536973, 8536974, DE702HD, 1925071, AH3494614, AP6019303, AP5177441, EA3494614, EAP11752609, PD00002518, PS3494614, PS11752609, 661570V, 661570, 3387610, 3389728, 3393999, 339728, 661570VP, 4248258, AP5983729, EAP382430, PD00023608, PS382430, PS11722115, W10837240, W10547290, W10837240VP, W10547287, 3387372, 3388674, W10118754, W10118756, W10837240VP, DE8756, B0189H5EHE, B001GDEXIK, B00DM8L9JI, B015QT17AQ, B00HNEJHRS, B008DJZYE2, B00E9DTL1S, B008DJTXX0, 4337602, AP5988716, EAP11726337, PD00025564, PS11726337.

Features:

• Supports the dryer drum.
• Heavy duty drum roller.
• For even wear, it’s recommended to replace all the rollers at the same time.
• Includes (4) Support Rollers, (4) Washer, (8) Tri-Rings.

APNW10314173 Roller Specifications:

• Color: Black / Dark Green.
• Material: Rubber / Plastic / Metal
• Dimensions: 3-1/8″L x 1″W x 3-1/8″H.

APN661570 Belt Specifications:

• Color: Black.
• Material: Rubber.
• Overall Dimensions: 93-1/2″L x 1/4″W x 1/8″H.

APNW10837240 Idler Specifications:

• Color: White.
• Material: Plastic / Metal.
• Overall Dimensions: 6-1/4″L x 1-1/4″W x 3-7/16″H.
• Pulley Dimensions: 2-1/8″ diameter.
